SNS Air Compressor Pressure Regulator With Bracket and Gauge Female Thread 1'' NPT 0-150 PSI Adjustable AR5000-N10
Product details
| Management number | 211131966 | Release Date | 2026/04/04 | List Price | $13.79 | Model Number | 211131966 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Thread: 1'' NPT
- Rated Flow: 282.6 SCFM (8000 L/min)
- Temperature Range: 5~60 ℃ (41-140 ℉)
- Aluminum Alloy Material
- When regulating pressure, pull up the rotary knob and rotate clockwise to increase the pressure and rotate anticlockwise to decrease the pressure
| Size | 5000-N10 |
|---|---|
| Brand Name | SNS |
| Unit Count | 1.0 Count |
| Valve Type | Pressure Regulator |
| Thread Size | 1'' NPT |
| Thread Type | NPT |
| Manufacturer | China SNS Pneumatic Co.,Ltd |
| Model Number | AR5000-N10 |
| Material Type | Aluminum |
| Connector Type | Threaded |
| Number of Ports | 2 |
| Maximum Pressure | 150 Pound per Square Inch |
| Specification Met | ASME, UL, CSA, RoHS, EPA, ANSI B16.11, UPC, CE, ASSE |
| Inlet Connection Size | 1 Inches |
| Inlet Connection Type | National Pipe Tapered |
| Outlet Connection Size | 1 Inches |
| Outlet Connection Type | NPT |
